Dear Community,
i’m new to Shapr3D but until now i managed to design everything iw anted as i wanted using the tutorials. Now i have to “reengineer” a hip flask (see attached drawing).
I managed tho create the Body itself, no problem, but how do I create the second bend (seen from above)?
I am grateful for any help!
HipFlask.pdf (1.9 MB)
You need to create several sketches from different views. Then extrude all of them and then intersect. Will add video in a couple of minutes.
This is very quick example, you still have to manage all the sizes correctly.
Far from finished product, just another quick test.
wow, thanks a lot Xdrakosha!!!
Just a little more efforts
Hey @Xdrakosha
And how do I clean this flat???
Mit freundlichen Grüssen
Andreas Desiderius Haudenschild
I don’t know how to clean a flat — I own a house.
On a serious note, I have no idea what this is referring to.
Hey @Xdrakosha
Sorry, I meant hip flask.
Actually, I know the hip flask from the army.
And the bottle has a min. Capacity of one liter.
Mit freundlichen Grüssen
Andreas Desiderius Haudenschild
Great. But what exactly do you want to clean? What I showed in the last video doesn’t require any cleaning.
This is the result of intersection and a couple of filets, that’s all.
That’s right, but the bottle should be thoroughly cleaned at some point. And this form you have chosen is very tedious to clean.
Mit freundlichen Grüssen
Andreas Desiderius Haudenschild
Sorry, I don’t understand you.
I didn’t choose the shape — I just showed how to do what the person wanted to achieve. Maybe that question wasn’t even addressed to me.
Maybe it was just a misunderstanding.
To me, the bottle looks like a perfume bottle.
I understood that you only explained the technical possibility with the program. So how to make the design according to the template.
Mit freundlichen Grüssen
Looks like it. I honestly thought you were asking how to clean up the 3D model
May be.
Hey @Xdrakosha
To me it looks like it’s a glass bottle
Mit freundlichen Grüssen
Andreas Desiderius Haudenschild
Hi,
Step by step, an other process with the plan…
Sketch on plan, Loft, Extrude Intersect, Revolve+Union and finish with fillets.
You can view it here .
